Phaetus aeWorthy™ ABS-GF Filament 1kg Spool
Phaetus aeWorthy™ ABS-GF is an ABS-based filament specially developed for 3D printing and it is reinforced with 10% glass fiber. Compared with other ABS filaments, it has a much lower odor...
Description
Phaetus aeWorthy™ ABS-GF is an ABS-based filament specially developed for 3D printing and it is reinforced with 10% glass fiber. Compared with other ABS filaments, it has a much lower odor and excellent dimensional stability.
| Property | Testing method | Typical value |
| Density | ISO 1183 | 1.10g/cm³ |
| Glass transition temperature | ISO 11357 | 101℃ |
| Melt index | 250℃，2.16kg | 4g/10min |
| Vicat softening temperature | ISO 306 | 106℃ |
| Determination of temperature |
ISO 75：Method A ISO 75：Method B |
92℃ (1.8MPa) 96℃ (0.45MPa) |
| Tensile breaking strength | ISO 527 | 39.28±0.93MPa |
| Elongation at break | 2.43±0.20% | |
| Young’s Modulus | 2826±56MPa | |
| Tensile breaking strength | ISO 527 | 19.02±0.9MPa |
| Young’s Modulus | 2331±130MPa | |
| Elongation at break | 1.28±0.32% | |
| Bending strength | ISO 178 | 66.21±0.42MPa |
| Bending Modulus | 2681±24.99MPa | |
| Charpy impact strength | ISO 179 | 8.17±0.66KJ/㎡ |
Additional Information
| Color |
Black, Grey, Red, Orange, Yellow, Blue |
|---|
Phaetus aeWorthy™ ABS-GF Filament 1kg Spool
$29.99
