The only Black Friday deal you need... until the next one.
Some highlights:
440c rails, RNC coated gears, full CAN bus setup, included hotend, TC nozzle, rabbit kit, Ti backers, kinematic mount. LEDs out the wazoo. Check the jump for the rest.
| Trident Structural | |
| Voron Trident frame 250 x 350 x 350 white | 1 |
| Voron Trident stainless steel fasteners kit | 1 |
| Black din rails 478mm | 2 |
| Black EPDM rubber Feet | 4 |
| Trident Motion | |
| dfh.fm 440c stainless steel MGN9H linear rail 400mm | 2 |
| dfh.fm 440c stainless steel MGN9H linear rail 300mm | 3 |
| dfh.fm 440c stainless steel MGN12H linear rail 400mm | 1 |
| dfh.fm Voron Trident motors kit | 1 |
| F695-2RS bearings | 20 |
| Runice 20T B5 W6 pulley black | 3 |
| Runice 20T B5 W6 idler black | 2 |
| Igus pressfit bearing EGLM-05 | 3 |
| Gates LL 2GT 6 RF Belt | 6 |
| Black POM TR8 lead screw spring nuts | 3 |
| Trident Cooling | |
| GdStime 5015 24v dual ball blower fan | 1 |
| GdStime 4010 24v dual ball axial fan | 1 |
| GdStime 6020 24v dual ball axial fan | 1 |
| Trident Extruder/Hotend/Nozzle | |
| Runice BMG style gears kit (RNC coated) | 1 |
| ECAS04 push fit | 1 |
| Orange Tube clip for ECAS04 | 1 |
| PTFE tube (300mm) | 1 |
| FEP tube (clear) (1.5m) | 1 |
| PC4-M10 Press fit | 1 |
| Phaetus Dragonfly BMO hotend black | 1 |
| Phaetus Tungsten carbide nozzle 0.4mm | 1 |
| Trident Bed | |
| 355mm spring steel sheet with Voron logo cut out black texture * 2 | 1 |
| dfh.fm black anodized ultraflat AA grade bed < 0.15mm | 1 |
| dfh.fm full plate heater 120v 800w | 1 |
| thermal fuse | 1 |
| Trident Electronics | |
| BTT SB2040 Can board | 1 |
| BTT CAN bus cable | 1 |
| BTT M5P 1.0 | 1 |
| BTT 2209 | 5 |
| Omron D2F-x Microswitches | 3 |
| BTT CB1 2.2 Pi replacement | 1 |
| Trident Electrical | |
| Mean-Well Power Supply: UHP 200-24 | 1 |
| Microfit connectors kit | 1 |
| JST-XH connectors kit | 1 |
| Stealthburner toolhead board connectors kit with LED | 1 |
| Spade fork terminals | 10 |
| Female spade terminals | 10 |
| C14 inlet with switch and fuse | 1 |
| Red 18 AWG FEP wire | 0.5m |
| Black 18 AWG FEP wire | 1m |
| White 18 AWG FEP wire | 0.5m |
| Green 18 AWG FEP wire | 0.5m |
| Omron SSR | 1 |
| Trident Display | |
| BTT Mini 12964 | 1 |
| Trident Extras | |
| Voron Trident kinematic mount kit by Lightweight Labware | 1 |
| Titanium backers set by Lightweight Labware | 1 |
| Titanium backers screws set | 1 |
| Black din rail ssr mount | 1 |
| Black four piece wire channel kit | 1 |
| 6 cart rabbit kit | 1 |
| Rainbow barf PCB | 1 |
| Disco Stick XXL | 1 |
What you'll need:
Wire (not much), 6020 dual ball axial fan (unless my shipment arrives, then i'll toss one in the box), panels, bed magnet.
Note: Supplies are limited. All kits ship with white frames. No changing colors.
